Stream - Domestic Auto-boosting Pumps - Hydro-SHS


  1. Widely used for domestic, commerical, industry field
  2. For water works, pressure station
  3. For restaurants, hotels
  4. For residential area, small villas, high-rise buildings


  • Single phase: 220V/50HZ(built in thermal protection)
  • Three phase: 380V/50HZ
  • Max speed: 2900rpm
  • Insulation class: F
  • Protection class: IP55
  • Output power range: 0.37-3kW

Working condition

  • Head range: 5-65m
  • Flow range: 1-16m³/h
  • Maximum operating condition: 10 bar
  • Medium: not frozen states, thin, clean, non flammable and explosive and liquid without solid and fiber

Medium temperature

  • Normal temperature: 0-50?
  • High temperature: 0-90?
  • Environment temperature≤50?
