Stream - Irrigation Deep Well Pumps - 4SG
- For water supply from wells, tanks or reservoirs.
- For domestic use, for civil and industrial appliations.
- For garden use and irrigation. Utilization of rain water.
- Max fluid temperature: up to 50?
- Max immersion: 80m
- Max sand content: 0.25%
- PH scope: 6.5-8.5
- Sand content: up to 0.01%
Motor and pump
- Rewindable motor
- Single-phase: 220-240V/50HZ
- Three-phase: 380-415V50HZ
- Equip with start control box or digital auto-control box
- Pumps are designed by casing stressed
- NEMA dimension standards
- Curve tolerance according to ISO 9906
Options on requeset
- Special mechanical seal
- Other voltage or frequency 60HZ
- Single phase motor with built-in capacitor
- Outlet parts are available with casting or SUS304 or iron
- Control box is available if needed.
