Stream - Domestic Centrifugal Pumps - SCPM

Applications and installation:

The SCPM series pumps are high-efficient, power-saving and compact in structure,convenient to operate and maintain. The hydraulic characteristic is with high head and small capacity. They are suitable for both domestic and industrial applications to convey clean water and non-aggressive chemical liquid, also canbe applied to supply the water for garden, hotel, villas and agricultural irrigation, etc.

Operating limitations:

  • Maxambient temperature up to 40 ?
  • Maxfluid temperature up to 80 ?
  • Maxpressure up to 10 bar

Construction features

  • Pump Body: cast iron
  • Motor Housing: aluminum
  • Shaft:45# steel/stainless steel
  • Impeller:brass /S/S optional
  • Motor:closed, externally ventilated
  • Insulation Class: B/F
  • Protection Class: IP44/IP54
  • Duty:continuously rated
  • Mechanical Seal: ceramic steatite/ metalized carbon
