Viking - Rotary Vane Pumps - Rotary Vane Pump
Series:
LVP
Max. Capacity: 160 GPM (36 M³/hr)
Max. Pressure: 200 PSI (14 BAR)
Max. Viscosity: 2,300 SSU (500 cSt)
Temperature Range: -15°F to +225°F (-30°C to +110°C)
Features:
- High pressure and high efficiency with thin liquids.
- Pump design offers ANSI or DIN flanges, and IEC or NEMA motor mounts to conform to international standards for enhanced application flexibility.
- 20 minute in-line vane replacement reduces scheduled downtime.
- Harder components than other vane pumps extend pump life.
- 62 Rockwell C surface-hardened one-piece, 316 stainless steel casing.
- Silicon carbide sleeve bearings.
- Chrome oxide shaft coating.
Specifications
| Material of Construction | Size | Standard Port | Nominal Capacity At Maximum Speed | Maximum Speed | Maximum Pressure | ||
| Inches? | GPM | M3/Hr | RPM | PSI | BAR | ||
| Stainless Steel | LVP40017 LVP41017 |
(1.5) 40 | 20 | 4 | 1,750 | 200 | 14 |
| LVP40027 LVP41027 |
(1.5) 40 | 40 | 9 | 1,750 | 200 | 14 | |
| LVP41057 | (2) 50 | 80 | 15 | 1,150 | 200 | 14 | |
| LVP41087 | (2) 50 | 100 | 23 | 950 | 200 | 14 | |
| LVP41197 | (3) 80 | 125 | 29 | 520 | 200 | 14 | |
| LVP41237 | (3) 80 | 160 | 36 | 520 | 200 | 14 | |
ANSI-compatible parts in inches, DIN-compatible parts in (mm)
Integral pressure relief valve is standard.
Options
Sealing / Coupling:
Component Mechanical Seal, Cartridge Mechanical Seal, Cartridge Triple Lip Seal
Porting:
Opposite (180°), Flanged (ANSI or DIN)
Mounting:
Foot Mount, Motor Mount
